| SR NO. | MACHINE NAME | IMAGE | MACHINE SPECIFICATION | MAKE | QTY. IN NOS |
|---|---|---|---|---|---|
| 1 | Vertical Machining Centre with ATC, 4th Axis |  |
Model VF 2 | HAAS | 2 |
| Table Size 900 x 400 | |||||
| Travel X-axis 760 MM | |||||
| Y-axis 406 MM | |||||
| Z-axis 508 MM | |||||
| 2 | CNC Turning Centre |  |
Super Jobber 500 LM | Ace Micromatic | 1 |
| Chuck Size - 200 MM | |||||
| Max Turning length -450 MM | |||||
| Max Turning Dia 280 MM | |||||
 |
Smart Turn | LMW | 2 | ||
| Chuck Size - 165 MM | |||||
| Max Turning length - 250 MM | |||||
| Max Turning Dia 250 MM | |||||
 |
Star Turn | LMW | 1 | ||
| Chuck Size - 135 MM | |||||
| Max Turning length - 160 MM | |||||
| Max Turning Dia 180 MM | |||||
| 3 | CNC Turn Mill Centre |  |
Chuck Size - 135 MM | Neri | 1 |
| Max Turning length -150 MM | |||||
| Max Turning Dia 180 MM | |||||
| 2 Arial Live Tool | |||||
| 1 Radial Live Tool | |||||
| 4 | Capstan Lathe |  |
RDU 28 | Gedee Weiler | 3 |
| Bore Capacity 28 MM | |||||
| Max Turning length -100MM | |||||
| 5 | Drilling Machine |  |
1/2" Drilling 1HP Motor | KMP | 4 |
| High Precision 12000 RPM Max | Thakoor | 1 | |||
| 6 | Drill & Tap Machine |  |
MultiSpindle | KTA | 1 |
| Range-18 to 110 MM | |||||
| Spindle 4 Nos | |||||
| Drill Tap Capacity 6MM | |||||
| 7 | Centre lathe |  |
Chuck Size 160 MM | Anil | 1 |
| Max Turning lenght 400MM | |||||
| Max Dia Turning 135MM | |||||
| Chuck Size 400 MM | Tos | 1 | |||
| Max Turning lenght 1000MM | |||||
| Max Dia Turning 250MM | |||||
| 8 | Bandsaw Machine |  |
Max Cutting size 200MM | Krishna | 1 |
| 9 | Forging PRESS |  |
Capacity - 100 Tons | Birson | 2 |
| Screw Dia - 140MM | |||||
| Stroke - 200 to 450MM | |||||
| Power - 10 H.P/ 1440 RPM | |||||
| 10 | POWER PRESS/ Punching. |  |
Capacity - 20 Tons | Birson | 1 |
| Power - 2 H.P/ 1440 RPM |
| NO. | INSTRUMENT | MAKE | RANGE | LEAST COUNT | QTY |
|---|---|---|---|---|---|
| 1 | Co-ordinate Measuring Machine (CMM) | Hexagon | 600MM X 800MM X 600MM | 0.0001 | 1 |
| 2 | Electronic Height Gange | Micro technika | 0-625mm | 0.005 | 1 |
| 3 | Surface plate | Micro Flat Datum | 800X600mm | 00 | 1 |
| 4 | Digital profile Projector | Innovative | DPP 1510 | 0.005 | 1 |
| 5 | Dial - Vernier | Mitutoyo | 0-150mm | 0.02 | 3 |
| 6 | Dial - Vernier | Mitutoyo | 0-200mm | 0.02 | 1 |
| 7 | Vernier Caliper | Ocean | 0-300mm | 0.02 | 1 |
| 8 | Digital Vernier caliper | Baker | 0-150mm | 0.02 | 1 |
| 9 | External Micro Meter | Mitutoyo | 0-25mm | 0.01 | 2 |
| 10 | External Digital Micro Meter | Mitutoyo | 0-25mm | 0.001 | 1 |
| 11 | External Digital Micro Meter | Mitutoyo | 25-50mm | 0.001 | 1 |
| 12 | External Micro Meter | Mitutoyo | 50-75mm | 0.01 | 1 |
| 13 | External Micro Meter | Mitutoyo | 0-100mm | 0.01 | 1 |
| 14 | External Micro Meter | Baker | 100-125mm | 0.01 | 1 |
| 15 | External Micro Meter | Baker | 125-150mm | 0.01 | 1 |
| 16 | External Micro Meter | Ocean | 150-300mm | 0.01 | 1 |
| 17 | Depth-MicroMeter | Mitutoyo | 0-25mm | 0.01 | 1 |
| 18 | I.D.Caliper | Insize | 10-30mm | 0.01 | 1 |
| 19 | Bore Gauge | Mitutoyo | 18-35mm | 0.002 | 1 |
| 20 | Bore Gauge | Mitutoyo | 35-60mm | 0.002 | 1 |
| 21 | Bore Gauge | Mitutoyo | 50-150mm | 0.002 | 1 |
| 22 | Plunger Dial | Mitutoyo | 0-10mm | 0.01 | 2 |
| 23 | Lever - Dial | Mitutoyo | 0-0.8mm | 0.01 | 2 |
| 24 | PIN - Gauge Set | Micro Gauge | 0.5-14 mm (0.05 step) | 0.005 | 1 |
| 25 | Radius - Gauge | KriSteel | R1.0 - R15mm | 1 | |
| 26 | Thread - Gauge | Baker | Metric - British | 1 |
